Oil Storage Tank, Oil Tank

Brand: Henan Victor Machinery Equipment Co.,Ltd
Product origin: Made In China
Product No: Grain and oil storage-44

Our company can produce different types of tubing according to the different needs of customers, which can be shipped from China, or we can arrange engineers to go abroad for on-site welding

Oil Storage Tank, Oil Tank details

100m³ - 20000m³ vertical crude oil storage tank / oil storage tanks above ground

Product description

An oil storage tank is a container for storing oil. The main facilities of the oil depot. In pipeline transportation, it is the oil source interface of oil pipeline. It is a container for storing crude oil or other petroleum products consisting of tank wall, tank top, tank bottom and tank accessories.

soybean oil tank,Oil storage tank,palm oil tank,peanut tank

The large storage tanks of various specifications and models can be made. We can choose different types and different materials storage tanks according to the properties of the materials.

Technical parameter

Main Materials in Carbon Steel	Q235
Cylinder	Φ13,368 × 15,000mm
Roof Type	Fixed dome roof

Bill of material

Bottom plates	8mm Annular Bottom
Shell	1st circle 10mm
	2nd circle 8mm
	3rd circle 8mm
	4th circle 8mm
	5th circle 8mm
	6th circle 6mm
	7th circle 6mm
	8th circle 6mm
	9th circle 6mm
	10th circle 6mm
Top plates	6mm

Design conditions

Service	Crude oil
Design temperature	-19℃ - 90℃
Design pressure	-490Pa - 1960Pa
OP.TEMP	Normal TEMP
OP.PRESS	Normal PRESS
Testing (Installation)	Full of water Test
Painting	External(YES)
	Iron red alkyd anti-corrosive primer -twice
	Alkyd finish paint - twice
	Total thickness: 150μm
	Internal(NO)

Tank specification sheet(inner floating roof)

Tank specification sheet(inner floating roof)
Nomial volume (m³)	Tank inner diameter(mm)	Tank bottom diameter(mm)	Tank wall height(mm)	Dome radius (mm)
100	4500	4620	8030	5000
200	5500	5620	9810	6000
300	6500	6620	10700	7000
400	7500	7620	10700	8000
500	8200	8320	10700	9000
600	9000	9120	10700	9000
700	9200	9340	12480	9500
1000	11500	11640	12480	13000
2000	14500	14650	14260	17000
3000	17000	17150	16040	17000
5000	21000	21160	16040	21000
10000	31000	30180	16040	31000
20000	42000	42180	17820	42000

tag : soybean oil tank,Oil storage tank,palm oil tank,peanut tank

Oil Storage Tank, Oil Tank,Our company can produce different types of tubing according to the different needs of customers, which can be shipped from China, or we can arrange engineers to go abroad for on-site welding
