VICTORY designs advanced and professional crude small palm oil refining machine to obtain high purity refined oil. It contains hydrated degumming, alkali refining deacidification, negativepressure decoloring process through blenching earth, deodorizin
Good quality made in China Oil Refining Machine details
1. Introduction of small palm oil refining machine :
The daily processing capacity of refining is 1-100TPD
1.1.Degumming Section: Some impurity, such as Phospholipid, gum, and protein, can be dissolved into oil when there is no water, but once there is water in oil, these impurity can be dissolved into water. So in degumming section, we use the hot water to wash crude oil for two-three times to remove these impurity.
1.2.Neutralizing Section: Crude oil contains much free fatty acid, which is harmful for health. Free fatty acid can have the reaction with caustic soda, during the reaction, it can be saponified and becomes soapstock, then small soapstock pellets will sink and becomes sediment and be pumped out. After neutralizing, most of the free fatty acid will be removed out.
1.3.Decoloriztion Section: Most of the crude oil has deep color because of the pigments, such as carotene,xanthophyll, etc. We use bleaching earth to remove pigments, because bleaching earth has strong adsorption capacity. Then pump oil into plate filter to remove bleaching earth, then pigment also will be removed out along with bleaching earth, then oil will be clean and transparent.
1.4.Deodorizing Section: Pure oil has no smell, but different crude oil has their special smell because of some volatile matters, for example the oxide for ketones, aldehydes, hydrocarbons. In deodorizing section, we deliver steam into oil continuously, and make sure steam and oil can fully contacted under high temperature and pressure, then volatile matters can be removed out along with the steam.
The daily processing capacity of refining is 1-100TPD
1.1.Degumming Section: Some impurity, such as Phospholipid, gum, and protein, can be dissolved into oil when there is no water, but once there is water in oil, these impurity can be dissolved into water. So in degumming section, we use the hot water to wash crude oil for two-three times to remove these impurity.
1.2.Neutralizing Section: Crude oil contains much free fatty acid, which is harmful for health. Free fatty acid can have the reaction with caustic soda, during the reaction, it can be saponified and becomes soapstock, then small soapstock pellets will sink and becomes sediment and be pumped out. After neutralizing, most of the free fatty acid will be removed out.
1.3.Decoloriztion Section: Most of the crude oil has deep color because of the pigments, such as carotene,xanthophyll, etc. We use bleaching earth to remove pigments, because bleaching earth has strong adsorption capacity. Then pump oil into plate filter to remove bleaching earth, then pigment also will be removed out along with bleaching earth, then oil will be clean and transparent.
1.4.Deodorizing Section: Pure oil has no smell, but different crude oil has their special smell because of some volatile matters, for example the oxide for ketones, aldehydes, hydrocarbons. In deodorizing section, we deliver steam into oil continuously, and make sure steam and oil can fully contacted under high temperature and pressure, then volatile matters can be removed out along with the steam.
2. Advantages of our small palm oil refining machine
2.1 Advanced designed oil refinery process
VICTORY designs advanced and professional crude small palm oil refining machine to obtain high purity refined oil. It contains hydrated degumming, alkali refining deacidification, negative pressure decoloring process through blenching earth, deodorizing to remove odor components in oil, and dewaxing to remove wax in oil. The heat conduction oil boiler can supply above 280°C energy to each device, steam generator can supply steam for deodorizing and distillation, vacuum pump can supply vacuum for dehydrate, decolor and deordor. The press filter is used to filter clay and filter out clear oil, and air compressor to blow dry blenched clay and empty the leftover oil in press filter.
2.2 Automatic control system assures high efficiency oil refinery
The application of advanced automatic control system in large oil refining plant provides the most secured, reliable production in entire workshop and monitors the operation status by controlling the computer terminals.
2.3 Low production cost and high purity refined oil.
We adopts compact crude vegetable oil refinery process to obtain high purity refined oil with impurity less than 0.2%. The adoption of waste recycle system can protect environment efficiently.
VICTORY designs advanced and professional crude small palm oil refining machine to obtain high purity refined oil. It contains hydrated degumming, alkali refining deacidification, negative pressure decoloring process through blenching earth, deodorizing to remove odor components in oil, and dewaxing to remove wax in oil. The heat conduction oil boiler can supply above 280°C energy to each device, steam generator can supply steam for deodorizing and distillation, vacuum pump can supply vacuum for dehydrate, decolor and deordor. The press filter is used to filter clay and filter out clear oil, and air compressor to blow dry blenched clay and empty the leftover oil in press filter.
2.2 Automatic control system assures high efficiency oil refinery
The application of advanced automatic control system in large oil refining plant provides the most secured, reliable production in entire workshop and monitors the operation status by controlling the computer terminals.
2.3 Low production cost and high purity refined oil.
We adopts compact crude vegetable oil refinery process to obtain high purity refined oil with impurity less than 0.2%. The adoption of waste recycle system can protect environment efficiently.
